Outside Dimension(mm)LxWxH

24000x5000x3200

Painting Room Dimension(mm)LxW

4900x4900

Drying Room Dimension(mm)LxW

18950x4900

Door Dimension(mm) LxW

1900x2200

Sliding door

One sliding door, 2000mm*2200mm,connected paint booth with drying booth.The finished products could be moved into the drying room through this door.

Wall Panels

50mm EPS colorful steel skin panel, steel 0.4mm thick, tongue groove style,

Lighting System

Painting room: 18pieces x16w LED lamp ; Baking room: 16 pieces x 16w LED lamp.

Ventilation Sytem

Air in : 2 sets4 kw YDW double-intake centrifugal fans,total air capacity: 25000m³/h.Air out :1 set 7.5kw YDW double-intake centrifugal fans,total air capacity: 18000m3/h

Heating System

12 pieces x3kw shortwave infrared halogen baking lamps .

Filter System

Intake air: : primary filter ,ceiling filter .

Water curtain system

Grilles: 30mm*4mm flat iron,12#channel steelWater Curtains Dimension:4000x400x1500mm(LxWxH),stainless steel.Water Pump Brand:Lailibao, capacity:7m3/h, lift:18m, rotate speed:2860 rotate/m power:1.1KW

Control System

Lighting switch, spraying, baking temperature, time setting, emergency stop,temperature controller, power supply.

Total Power

52 kw (3Phase,380V,50HZ)
